CCXC 12P M to F Cables Compatiable with Sony/Pulnix/Panasonic Cameras

Product Details:

Place of Origin:China
Brand Name:DHT
Certification:CE/ROHS/FCC/SGS/UL
Model Number:HR040-R2

Payment & Shipping Terms:

Minimum Order Quantity:100pcs
Price:negotiation
Packaging Details:1 piece  per PE Bag then 20pcs per carton
Delivery Time:3 - 7 working days
Payment Terms:T/T or Paypal
Supply Ability:300,000pcs per month


Detailed Product Description

Material:CopperInterface Type:Hirose
Pin:12pinApplication:Machine Vision
Power Cable Type:12pin CoaxialFeature:Chain Flex
Computer Cable Type:Data TransmissionPrinter Cable Type:Coaxial
4.0meters:High Flex Chain Black25meters:Overmolded


CCXC 12P M to F Cables Compatiable with Sony/Pulnix/Panasonic Cameras


Product Description:


Sony Compatible 12Pin to 12Pin M to F CCXC-12 Style Cables.

  • For Sony XC and DXC Series Cameras

CCXC-12P02N  2Meters
CCXC-12P05N  5Meters
CCXC-12P10N  10Meters
CCXC-12P25N  25Meters

Offer standard length and custom length

Pulnix Compatible 12Pin to 12Pin M to F CCXC 12P Style Cables


  • For Pulnix TM and TMC Series Cameras

CCXC-12P02N  2M
CCXC-12P05N  5M
CCXC-12P10N  10M
CCXC-12P25N  25M

Offer standard length and custom length

Compatable with Panasonic GP and KX Cameras, alternative Hitachi C201-KSN,C501-KSM,And Intercon VCP-1.0-S, VCP-2.0-S, VCP-3.0-S, VCP-5.0-S, VCP-10-S Cables

Flexible Hirose 12Pin Male To Female Data Cable Pin To Pin Soldar Type CCXC-12P05N


Specification


The 12Pin connector is Japan original which can be molded at two ends,with high flex 5.0meter cable body,full shieding and good performance on motion system.


It has the following standard pin configuration and signal usage.


Pin 1  GND

Pin 2 +12 VDC

Pin 3  VIDEO GND

Pin 4 VIDEO OUTPUT

Pin 5 GND

Pin 6 HD SYNC INPUT

Pin 7 VD SYNC INPUT OR TRIGGER

Pin 8 GND

Pin 9 AUX SIGNAL

Pin 10 AUX SIGNAL

Pin 11 TRIGGER INPUT

Pin 12 GND


Guarantee


One-Year Warranty


Cable PDF:

12-12 CCXC.pdf
