​Hirose Extension Cables with HR10-10J-12P or HR10A-10J-12S Male to Female Coupler Connectors for CCD Cameras

Product Details:

Place of Origin:China
Brand Name:DHT
Certification:RoHS UL
Model Number:12pin cable

Payment & Shipping Terms:

Minimum Order Quantity:1pc
Packaging Details:1pcs Indivadual packing and 20pcs per carton
Delivery Time:1~2Weeks
Payment Terms:T/T
Supply Ability:1000Pcs/Month

Detailed Product Description

Molding:YesApplication:AOI , Chain Flex System

Hirose Extension Cables with HR10-10J-12P or HR10A-10J-12S Male to Female Coupled Connectors for CCD Cameras



12Pin Hirose Male to Female coupled connector

HR10-10J-12P /  HR10A-10J-12S(73),  HR10A-10P-12S(73) / HR10A-10P-12P(73)

HR10-10J-12P or HR10A-10J-12S(73) is a Circular Push Pull Connectors 12Pin, JACK SHELL FEMALE solder type connector can connect with HR10A-10P-12S(73) or HR10A-10P-12P(73)


1,Coaxial standard cable

2,Coaxial  High flex and Drag chain cable

Pin Assignment:

pin to pin


This is Circle connector hirose series high flex and drag chain sony camera adapter / extension cable
Cable length 0.5meter ~2Meters with 12-pin female to 12-pin male hirose coupled connector,this female connector can connect with male connector to extend cable distance as a extension cable,cable length can be customized.

This high flex cable can be used in standarded environment and also can bu used in industrial vision system,,robotics,drag chain system,AOI equipment and dynamic moving systems.

One end HR10A-10P-12S(73) or HR10A-10P-12P(73) designed to fit all standard 12-pin cameras,industrial camera with hr10a-10r-10pb or hr10a-10r-12s interface, and connectors on Hitachi and Sony Cameras, as well as most other industry standard cameras that use a 12-pin connection.

One end HR10A-10J-12P  or HR10A-10J-12S designed to fit and as extender to all 12pin hirose cable with HR10A-10P-12S(73) or HR10A-10P-12P(73)


1,With 12pin Hirose Male to Female coupled connector Solder and Molding type

2,Hirose Connector 100% Janpanese Original,alternative materiel avaiable

3,Cable at standard length in stock for immediately delivery

4,180 degree straigth end, 90 degree in other orientation and angled  type is available

5,Use ultra flex cable can endure millions bending fatigue test

6,Full shielded,good signal

7,Cable length can be customized according to user's requirements

8,1~2 years guarantee
