USB3.0 High Flex Cable Type A to Micro B with Screw Locking in Color Violet 3 meters for Automation and Robotics

Product Details:

Place of Origin:China
Brand Name:DHT
Model Number:USB2.0 USB3.0

Payment & Shipping Terms:

Minimum Order Quantity:100pcs
Packaging Details:1 piece  per PE Bag then 20pcs per carton
Delivery Time:3 - 7 working days
Payment Terms:T/T or Paypal
Supply Ability:300,000pcs per month

Detailed Product Description

Material:CopperInterface Type:USB2.0 USB3.0
Computer Cable Type:Data CablePrinter Cable Type:Parallel
5meters:PurpleMax Length:10m With PCB Signal Magnifier

USB3.0 High Flex Cable Type A to Micro B with Screw Locking in Color Violet 3 meters for Automation and Robotics


While conventional USB cables often break rather quickly when subjected to constant movement, High Flex cables emerges as the optimal option for such application.

Constructed using custom special materials, high flex cables are rated for up to 5 million flex bending cycles.

The cables are ideal for dynamic applications that are subjected to continuous flex movement, such as machine vision applications, robotic productions, movements with assembly and package machinery, medical imaging capturing, etc.

1,The cable color is violet, high flex usb2.0/usb3.0 cable and connector for options.

2, The use of bending resistance cable is specially for moving system,drag chain system automation equipment, AOI, motion detection, motion control and high-end communication equipment etc...

3, The specific screw hole distance please contact us miss wang. Commonly used M2 thumbscrew.

3, Both ends of high-quality plug, the contact finger is gold plated material, to ensure good contact and 100% copper conductor ensure the signal communication.

4, About use of lifetime, we promise 10 million times, test methods, and bending radius, bending frequency per day, the complexity of the motion directions are related, so the bending life is not an absolute value, the bending radius and movement frequency please communicate with us to understand.


  • Support SuperSpeed data rate up to 5Gbps

  • 5 million flex life supported

  • Custom cable solutions

  • USB3 Vision Compliant Screw Locking

  • Rugged overmold interfaces

  • Flame retardant and oil resistant


  • Max. flex bending life: 5 million

  • Outside Diameter: 7.0mm

  • Custom cable solutions

  • Operating Temperature: -22 ℉ - 176 ℉(-30 ℃ - 80 ℃)

  • Min. Static Bend Radius: 5 x OD

  • Min. Dynamic Bend Radius: 10 x OD

  • UL Recognized AWM

  • RoHS Compliant

  • The USB3.0 Data Cable High Flex Type A to Micro B with Screw Locking in Color Violet 3 meters is designed for applications where ordinary USB cables can not do, this exclusive ultraflex cable is industrial grade at 5~10million flex cycle life time. The special bulk cable uses a polyurethane jacket plus high strand count data (28 AWG) and power (24 AWG) conductors to achieve the extra durability. Available with type A-A and A-B A-Micro B w/s connector options,type A with screw locking available,in lengths ranging from 0.5 to 5 meters.
