30 Meters USB3.0 Hybrid Active Fiber Optic Cable Durable Million Times Repeated Bending Performance Fatigue Test





Descriptions:

USB 3.Optical™ Cables

  • 5 Gb/s data rate

  • Compatible with most USB 3.0 and 2.0 devices

  • Ultra-slim, “zero-bend” radius cable

  • Requires no external power supply to extend USB device reach

  • Hot swappable

  • Built in overcurrent protection

  • Extend USB 3.0 Distance up to 100 - 300m

  • Support USB 3.0 @5Gbps

  • Low Power Consumption

  • Longer, Thinner Cable without EMI/RFI Emissions


Specifications:


USB 3.Optical™ Cables by Corning connects computers and devices at incredible speed and over longer distances. They’re thin, light and remarkably tough — Optical Cables by Corning can be bent, squeezed, and tangled.

Available in 10m, 15m, 30m, and 50m lengths.

Distance
Computer/Host to Device: Up to 30 m/100 ft

Connector
Type A Plug to Type A Receptacle

Environmental
Operating Temperature: 0° to 45°C (32° to 113°F)

Compliance
Emissions: FCC Class (B), CE
Regulatory: RoHS, UL 758, AWM VW-1
Maximum Cable Tensile Strength: 33 lbs
Eye Safety: Class 1 Laser Product per IEC 60825-1
UL Listing Mark: Meets Safety Requirements — Category AOC

Applications:

  • Digital Home Theater

  • Supervisory Camera

  • Automatic Optical Inspection (AOI) for Machine Vision

  • Digital Signage and TV Wall

  • Zero Client Connectivity (Ex. Windows MultiPoint Server 2011/2012; One Computer for Multiple Users by Using USB 3.0 AOC and Zero Client Docking Station)

  • Signal Extender

Are USB 3.Optical™ Cables by Corning compatible with all USB devices?

Though no USB standard currently exists for optical cables, USB 3.Optical Cables by Corning have been successfully tested with more than a hundred devices spanning all major consumer operating systems. In general, you can expect USB 3.Optical Cables by Corning to work with most self-powered USB 3.0/2.0 compliant device.
